Additel ACal - Pressure Calibration Software

Additel ACal – Pressure Calibration Software

Additel ACal is a powerful software package designed to automate or semi-automate calibrations and manage your laboratory. ACal combines the pressure and temperature automation features with lab and asset management functions to help make your job easier and more productive.

ACal comes in three versions: Basic, Professional, and Network.

ACal Basic supports asset management and task management features.
ACal Professional is a single PC installation which combines all the features of Basic with automation functionality.
ACal Network puts the Professional version on a multi-user network platform.

SKU: 9530

Version

Clear

Add to Quote

Circular loading icon. A gray radial array of rounded rectangles indicates a process is in progress. Loading symbol for websites and apps.

Supports multi-users and network environments
Calibration and asset management
Simple user interface
Scanning and printing of QR codes
User definable permissions and access levels
Supports various units
Can calibrate a variety pressure and temperature instruments
Can calibrate several instruments at a time
Calibration planning and scheduling
Certificate management and creation
Certificate customization

Category	Type	Function	ACal Network	ACal Professional	ACal Basic
Networking		Database Sharing & Team Work	✓	✕	✕
Pressure Calibration	DUT	Dial Pressure Gauge	✓	✓	✓
		Digital Pressure Gauge	✓	✓	✓
		Pressure Transmitter	✓	✓	✓
		Pressure Switch	✓	✓	✓
		Full Automatic Pressure Calibration Solution	✓	✓	✕
Temperature Calibration	DUT	Noble Metal Thermocouple	✓	✓	✓
		Base Metal Thermocouple	✓	✓	✓
		Resistance Thermometer	✓	✓	✓
		Thermistor	✓	✓	✓
		Temperature Indication Controller	✓	✓	✓
		Temperature Transmitter	✓	✓	✓
		Temperature Switch	✓	✓	✓
		Liquid-in-Glass Thermometer	✓	✓	✓
		Filled System Thermometer	✓	✓	✓
		Bimetallic Thermometer	✓	✓	✓
		Digital Thermometer	✓	✓	✓
		Clinical Thermometer	✓	✓	✓
		Thermometers for Transformer Windings	✓	✓	✓
		Dry Well Calibrator Solution (ADT875/ADT878)	✓	✓	✓
		Laboratory Calibration Solution (ADT286)	✓	✓	✕
Calibrator Task Management		Download task to Calibrator	✓	✓	✓
		Upload data to ACal	✓	✓	✓
		Support Calibrator: ADT761/760/875/878/22x	✓	✓	✓
Cal Data & Certificates		Calibration Data Management	✓	✓	✓
		Certificate Management	✓	✓	✓
		User Template Management	✓	✓	✓
DUT Management		DUT Information Management	✓	✓	✓
DUT Management		Reminders & Schedules	✓	✓	✓
Reference Management		Reference Information Management	✓	✓	✓
Reference Management		Reminders & Schedules	✓	✓	✓
Label		Print Labels & Scan QR Codes	✓	✓	✕

Model Number	Description
9530-BASIC	Additel/ACal Automated Calibration software with asset management, basic version for one PC
9530-BASIC L1	Additel/ACal Automated Calibration software with asset management, basic version for one PC – additional license (9530-BASIC must be purchased prior to any additional licenses)
9530-PRO	Additel/ACal Automated Calibration software with asset management, professional version for one PC
9530-PRO- L1	Additel/ACal Automated Calibration software with asset management, professional version for one PC – additional license (9530-PRO must be purchased prior to any additional licenses)
9530-NET	Additel/ACal Automated Calibration software with asset management, network version for one user (also includes server installation package)
9530-NET- L1	Additel/ACal Automated Calibration software with asset management, network version for one user – additional license (9530-NET must be purchased prior to any additional licenses)
