We do stock several different variations of this product, and can special order others that are not in stock. Please contact us with your required spec and we can quote accordingly.
All variations shown in the product selector are typically ‘In stock’ subject to prior sales.
Contact us to confirm stock level before ordering.
If nil stock at time of order, lead time is typically ~4-6 weeks.
Price range: $164.00 through $462.00 ex. GST
The Shako SPU225A series, a 2/2 way (316SS) Stainless Steel Solenoid Valve, for use in harsh environments. Pilot operated for higher pressure applications.
Available in 3/8″, 1/2″, 3/4″ and 1″, 1-1/4″, 1-1/2″, 2″, BSP process connections (or special ordered in NPT)
We stock various versions including mostly ‘normally closed’ and some ‘normally open’ types, and can special order to meet your specifications. Contact us for a quote tailored to your needs.
A pilot acting valve requires some minimum pressure to open the valve but it can operate up to higher pressures.
| Model | SPU225A-03 | SPU225A-04 | SPU225A-06 | SPU225A-08 | SPU225A-12 | SPU225A-14 | SPU225A-20 |
| Port size | 3/8″ | 1/2″ | 3/4″ | 1″ | 1-1/4″ | 1-1/2″ | 2″ |
| Fluid | Compressed air (light oil, water) | ||||||
| Orifice | Ø13mm | Ø25mm | Ø38mm | Ø50mm | |||
| Effective area | 88mm² | 230mm² | 404mm² | 552mm² | 883mm² | ||
| Acting | Pilot acting | ||||||
| Diaphragm | Viton (standard), NBR, EPDM (option) | ||||||
| Operating pressure range | 0.5 ~ 10 kgf/cm² (50 – 1000 kPa) | ||||||
| Proof pressure | 15 kgf/cm² (1500 kPa) | ||||||
| Body / Flange material | Stainless Steel SUS316 / SUS304, SUS316 | ||||||
| Fluid temperature | -10°C ~ 90°C | ||||||
| Ambient temperature | -10°C ~ 60°C | ||||||
| Installation | Horizontal | ||||||
| Duty cycle | 100% ED | ||||||
| Coil type | DIN | ||||||
| Protection class | IP65 (DIN 40 050) | ||||||
| Insulation class | F | ||||||
| Voltage tolerance | ±10% | ||||||
| Standard voltage | 220VAC, 110VAC, 24VDC, the other voltage is optional | ||||||
| Power consumption | Normally closed AC110V: 17.6VA, AC220V: 18.1VA,DC:15W | ||||||
| Net weight | 775g | 1550g | 2820g | 4665g | |||
We suggest to check the official datasheet for latest specifications
