A 1632 eMobility Analyser

A 1632 eMobility Analyser

The A 1632 eMobility Analyser is a special accessory designed for diagnostic testing of Electric Vehicle Supply Equipment (EVSE) together with supported METREL installation testers.




Typically In stock subject to prior sales. Contact us to confirm stock level before ordering.
If nil stock at time of order, lead time is typically ~4 weeks.

$3,111.00 ex. GST

Add to Quote

The A 1632 eMobility Analyser is a special accessory designed for diagnostic testing of Electric Vehicle Supply Equipment (EVSE) together with supported METREL installation testers. It supports verification of electrical safety and functional testing of Type 1 and/or Type 2 EVSE as well as testing of Mode 2 and Mode 3 electrical vehicle (EV) charging cables and communication monitoring between the charging station and the EV during charging. Fully supported professional station-based and cable-based report creation with MESM software.

  • Functional testing of EVSE via simulation of electrical vehicle’s CP and PP circuits.
  • Diagnostic testing of EVSE via simulation of errors on CP circuit (output side).
  • Electrical safety testing of EVSE.
  • Functional testing of Mode 2 EV cables via simulation of electrical vehicle’s CP and PP circuits.
  • Diagnostic testing of Mode 2 EV cables via simulation of errors on CP circuit (output side) and mains (input side).
  • Electrical safety testing of Mode 2 EV cables with installed IC-CPD protection.
  • Electrical safety testing of Mode 3 EV cables.
  • Accessible inputs/outputs for connection of safety testers.
  • Bluetooth communication with Metrel safety testers and Android devices with eMobility app.

Standards applied



  • EISinsp Competences: Low Voltage Electrical Installation Safety Inspection
  • EISc Competences: Low Voltage Electrical Installation Safety for Contractors and Maintainers
  • IEC/EN 61557 Electrical safety in low voltage distribution systems up to 1 000 V AC and 1 500 V DC – Equipment for testing, measuring or monitoring of protective measures – series
  • ISO 6469-3 – Electrically propelled road vehicles Safety specification Part 3: Electrical safety
  • EVSE Competences: Electrical Vehicle Supply Equipment Safety
  • EVSE construction and testing
  • Vehicles with an on-board generator
  • EVSE domestic installation testing
  • EVSE periodic inspection
  • Renewable power and car charging
