MI 2883 Energy Master

September 09, 2020




The MI 2883 Energy Master is a hand-held three phase power quality analyser, specially designed for energy logging and subsequently efficiency calculation. Reducing energy use reduces energy costs and may result in a financial cost saving. Energy Master serves as a perfect tool for long term logging and later post processing of recorded data. Large easy-to-read graphical colour display enabling the user on site analysis and data checks. The handy Quick Set buttons makes the instrument more user friendly and are allowing faster data overview. Advanced PC SW package PowerView3 enables detailed analysis of recorded data, direct reading from the microSD memory card, analysis of long term records and automatic creation of professional test report.




  • 3-voltage channels with wide measurement range: 0 … 1000 Vrms (CAT III / 1000 V);
  • 4-current channels with support for automatic clamp recognition and “on instrument“ range selection;
  • Automatic Smart Clamp detection and Smart Clamp range selection;
  • Compliance with power quality standard IEC 61000-4-30 Class S;
  • Complete power quality analysis according to EN 50160 including signalling and interharmonics;
  • Support for microSD memory card (8-GB supplied with the instrument) up to 32GB;
  • Color-coded input terminals and termi­nal labels to suit your application region;
  • Intuitive main menu and large icons that makes the equipment very easy to navigate and configure;
  • Powerful PC SW PowerView3 enables downloading, view, analysis of recorded data and professional report creation;
  • Flexible clamps (without additional power supply) are included in the Euro set.

PowerView PC SW platform contains a package of functionalities needed for profund evaluation of power quality phenomena and creation of complex reports like:

  • Data download
  • Predefined EN 50160 power quality test report
  • Data merge
  • Transfer of test data to other applications (MS Excel, MS Word, etc.)
  • Filtering of recorded data
  • Tool for repairing of downloaded results to prevent loss of data during transmission



Voltage inputs AC+DC
Number of inputs 4
Nominal voltage range (L – N) Phase (L-N): 50 … 1000 VRMS

Line (L-L): 50 … 1730 VRMS

Measuring range 10% … 150% of nominal voltage
Accuracy IEC 61000-4-30 Class S, ±0.5% of nominal voltage,
Sampling rate 7 kSamples per sec @ 50/60 Hz, sync with mains freq.
Mains frequency range 42,5 … 69,0 Hz ±10 mHz
Current inputs AC+DC
Number of inputs 4
Measuring range

(with A1227 flex clamps)

3 … 6000 ARMS ±1.5% of m.v.
Measuring range

(with A1281 iron clamps)

50 m … 1200 ARMS ±0.5% of m.v.
Functions Measuring range Accuracy
Power (P, Q, S, cos φ, PF…) Depends on voltage and selected clamps IEC 61557-12 Class 1
Energy Depends on voltage and selected clamps Active: IEC 62053-21 Class 1

Reactive: IEC 62053-23 Class 2

Harmonics (DC … 50th) 0 … 20% of nom. voltage IEC 61000-4-7 Class 1
Interharmonics (1 … 50th) 0 … 20% of nom. voltage IEC 61000-4-7 Class 1
Flicker 0.2 … 10 IEC 61000-4-15 Class F3
Mains signalling 0 … 15% of nom. voltage IEC 61000-4-30 Class S
Unbalance Voltage: 0.5 … 5.0%

Current: 0.0 … 20%

Temperature -10 … 85 °C ±0.5 °C
Dips, Swell 10 … 150% of nom. voltage ±0.2 % of nominal voltage

±1 cycle

Interrupts 0 … 10% of nom. voltage ±1 cycle
Memory 8GB microSD, up to 32GB supported
General recorder
Integration period 1s … 2h
Recorded signals > 1000 (voltages, currents, harmonics, power…)

Minimal, maximal and average value per interval

– Voltage events

– Custom alarms

Duration > 1 year (depends on size of SD card)
Display 4.3 inch color TFT (480 x 272)
Communication USB
Time synchronisation GPS receiver (A 1355)
Power supply 110 … 240 Vac or 6 x NiMh rechargable batteries, size AA
Overvoltage category CAT IV / 600 V or CAT III / 1000 V
Weight 1 kg
Dimensions 230 x 140 x 80 mm


  • Voltage: TRMS, peak, crest factor (4-channel);
  • Current: TRMS, peak, crest factor (4-channel);
  • Power (active, reactive, apparent);
  • Power measurements fully compliant with IEEE 1459 (active, non active, fundamen­tal, harmonic, load unbalance);
  • Unbalance, flicker measurement;
  • Harmonic and interharmonic analysis up to 50th harmonics, THD measurement;
  • Energy (active, reactive, generated, consumed);
  • Capturing and recording of power supply events (shutdowns, interruptions, swells, dips);
  • Power quality analysis according to EN 50160;
  • Recording up to 7 adjustable alarms;
  • Temperature measurement;
  • Power factor cos ϕ.
